July 2019
6-30
Xerox® B205/B215 Multifunction Printer Service Manual
Diagnostic Information
Initial Release
General Procedures / Information
DTMF 1 Line1 NA YES
DTMF 2 Line1 NA YES
DTMF 3 Line1 NA YES
DTMF 4 Line1 NA YES
DTMF 5 Line1 NA YES
DTMF 6 Line1 NA YES
DTMF 7 Line1 NA YES
DTMF 8 Line1 NA YES
DTMF 9 Line1 NA YES
Test Pattern Test Pattern 1 YES YES
Test Pattern 2 YES YES
Shading Test Shading & Print YES YES
Print YES YES
Scan Aging Status Display(ON/OFF) YES YES
Diagnostics
Mo
de
DC131 NVM Read/ Write 09-110 MHVBias MHV DC K Range: 0-20, Default: 10
Offset -30 ~ +30
(21 Steps / 3 interval)
YES YES
09-130 DevBias Deve DC K Range: 0-20, Default: 10
Offset -30 ~ +30
(21 Steps / 3 interval)
YES YES
09-120ATTRBias THV K Range: 0-20, Default: 10
Offset -30 ~ +30
(21 Steps / 3 interval)
YES YES
09-121 ATTRDup THV K_Dup Range: 0-20, Default: 10
Offset -30 ~ +30
(21 Steps / 3 interval)
YES YES
10-100 RdyTemp Ready Temp K Range: 0-20, Default: 10
Offset -20 ~ +20
(21 Steps / 2 interval)
YES YES
10-105 PrtTemp Print Temp K Range: 0-20, Default: 10
Offset -20 ~ +20
(21 Steps / 2 interval)
YES YES
09-100 LSU LD Power K Range: 0-20, Default: 10
Offset -20 ~ +20
(21 Steps / 2 interval)
YES YES
DC132 NVM Initialize Print NVM Initialization MHV DC K
Deve DC K
THV K
THV K_Dup
Ready Temp
Print Temp
LD Power K
YES YES
Fax NVM Initialization All Fax settings ini-
tialized
NA YES
Table 2 Diagnostic Mode Menu - Machine Test
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 B205 B215
