Xerox B205

July 2019
6-29
Xerox® B205/B215 Multifunction Printer Service Manual
Diagnostic Information
General Procedures / Information
Initial Release
Diagnostic Mode Menu - Machine Test
Table 2 Diagnostic Mode Menu - Machine Test
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 B205 B215
Machine Test DC305 UI Test
(R
ef. GP 9)
Press any key to start
YES NA
Modem Test Single Tone 1100Hz Line 1
NA YES
Single Tone 1650Hz Line 1
Single Tone 1850Hz Line 1
Single Tone 2100Hz Line 1
V.21 300 bps Line 1
V.27ter 2400 bps Line 1
V.27ter 4800 bps Line 1
V.29 7200 bps Line 1
V.29 9600 bps Line 1
V.17 7200 bps Line 1
V.17 9600 bps Line 1
V.17 12000 bps Line 1
V.17 14400 bps Line 1
V.34 2400 bps Line 1
V.34 4800 bps Line 1
V.34 7200 bps Line 1
V.34 9600 bps Line 1
V.34 12000 bps Line 1
V.34 14400 bps Line 1
V.34 16800 bps Line 1
V.34 19200 bps Line 1
V.34 21600 bps Line 1
V.34 24000 bps Line 1
V.34 26400 bps Line 1
V.34 28800 bps Line 1
V.34 31200 bps Line 1
V.34 33600 bps Line 1
On Line Quiet State
DRAM Test YES YES
ROM Test YES YES
Continuous
DTM
F
DTMF # Line 1 NA YES
DTMF *Line 1 NA YES
DTMF 0 Line1
NA YES
