July 2019
2-7
Xerox® B205/B215 Multifunction Printer Service Manual
05-100 / 900 , 05-500
Status Indicator RAPs
Initial Release
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
g
raves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gr
avi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
ei
ngeschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
L
a máquina podría activarse y ocasionar daños personales graves.
Procedure
Inspect the Paper Feed Sensor PWB, PL 4.4 Item 20, for damage or contamination. Remove
any debris from the sensor.
Enter Diagnostic Mode, GP
1, [DC330, [102] Feed Sens] to test the Paper Feed Sensor. The
sensor is OK.
YN
• Check for an open or short circuit and clear any contamination that is present.
• Install a new paper Feed Sensor PWB, PL 4.
1 Item 15.
Check CN15 (FFC) between the ADF Drive Motor and the Main PWB. The circuit is good.
YN
• Check for an open or short circuit and clear any contamination that is present.
• Install a new ADF Module, PL 1.
1 Item 13.
Clear all jammed sheets from the paper path. If the fault persists, install a new Main PWB, PL
1.1 Item 4.
05-500 DADF Jam RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
B205: Document Feeder Cover Open
B215: Jam in the Document Feeder
There is a jam in the document feeder or the d
ocument feeder top cover is not fully closed.
Initial Actions
• Clear the jam in the Document Feeder.
• Close the Document Feeder top cover.
Procedure
Check the circuit between the Top Cover Sensor, PL 1.2 Item 4, and the Main PWB, PL 1.1
Item 4. The circuit is good.
YN
• Check check for and remove any contamination present.
• Check for broken or defective wires or cables, repair as necessary.
Install a new Main PWB, PL 1.1.
To Next Page
