Xerox B205

July 2019
2-8
Xerox® B205/B215 Multifunction Printer Service Manual
05-920 , 06-100 / 200
Initial Release
Status Indicator RAPs
05-920 DADF Top Cover Open RAP
BSD-ON:BSD 2
Control Panel Fault Displayed
B205: NA
B215: Document Feeder Top Cover is Open
The Document Feeder or Document Feeder T
op Cover is not securely latched.
Initial Actions
• Close the Document Feeder unit.
• Close the Document Feeder top cover.
Procedure
Check CN15 (FFC) between the ADF Cover Sensor and the Main PWB. The circuit is good.
YN
• The FFC is fully seated in the connector on the Main PWB and the ADF PWB.
• The FFC is not broken, worn, or damaged.
• Install a new ADF Module, PL 1.
1 Item 13.
Install a new Main PWB, PL 1.1 Item 4.
06-100 / 200 LSU Motor RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
06-100 LS
U Error: The machine has detected that the Laser Scanner Unit (LSU) Drive Motor is
not
working correctly.
B205: LSU Motor error
B215: Device Error
06-200 LS
U HSync Error: The machine has detected that the Laser Scanner Unit (LSU) Drive
Mot
or is not working correctly.
B205: LSU Hsync Error
B215: Device Error
WARNING
Use eye protection when performing the following procedure. Failure to wear eye pro-
tection could result in serious personal injury.
DANGER: Porter des lunettes de sécurité pendant la procédure suivante. À défaut, de
g
raves blessures peuvent se produire.
AVVERTENZA: Indossare occhiali di protezione durante la seguente procedura. In caso
c
ontrario, si possono provocare gravi ferite.
VORSICHT: Folgende Verfahren dürfen nicht ohne Schutzbrille angewandt werden. Die
Nic
hteinhaltung dieser Regel kann zu ernsthaften körperlichen Verletzungen führen.
AVISO: Use gafas de protección para realizar el procedimiento siguiente. No proteger
l
os ojos puede ocasionar daños personales graves.
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
g
raves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gr
avi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
ei
ngeschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
L
a máquina podría activarse y ocasionar daños personales graves.
Procedure
Enter Diagnostic Mode, GP 1, [DC330, [110] LSU Motor1 Ready] to test the LSU motor. The
motor runs.
YN
Check the Flat Cable, PL 4.
1 Item 1, and connectors on the Laser Scanner Unit (LSU).
The connections are secure.
A
