July 2019
2-14
Xerox® B205/B215 Multifunction Printer Service Manual
08-100 , 08-500
Initial Release
Status Indicator RAPs
In Diagnostics Mode. Select: [102-Sensor, Feed Sens] to block and clear the Paper Feed
Sensor. The signal changes.
YN
1. Verify no contamination present in t
he Paper Feed Sensor PWB, PL 4.4 Item
20
.
2. Check the Paper Feed Sensor harness for damage or excessive wear, open, or
shor
t circuit.
3. Install a new Paper Feed Sensor PWB, P
L 4.4 Item 20.
Perform SCP Final Actions.
Check the Paper Feed Sensor harness for damage or excessive wear, open, or short circuit.
08-500 Paper Jam in Exit Area RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
B205: Wrap Jam Call for Service
B215: Jam in the Device
The machine has detected a paper jam in the Exit Area.
Initial Actions
Open the Rear Cover and remove jammed sheets from exit area. Refer to Section 11 in the
Xerox® B215/B205 User Guide for detailed instructions on clearing paper jams.
Check the Paper Guides for proper positioning.
Check the Duplex Gate, P
L 2.1 Item 7, and Spring, PL 2.1 Item 8, for damage. Ensure that the
Duplex Gate is seated correctly and moves freely without binding.
Procedure
Enter Diagnostic Mode, GP 1, [DC330, [102] Feed Sens] to block and clear the Exit Sensor.
The Exit Sensor is OK.
YN
1. Check that there is no contamination present.
2. Check for an open or short circuit.
3. Install a new Exit Sensor, PL 4.
1 Item 24.
In Diagnostics Mode. Select [102-Sensor, Registration] to block and clear the Registration
Sensor. The signal changes.
YN
1. Check that there is no contamination present.
2. Check for an open or short circuit.
3. Install a new Paper Feed Sensor PWB, PL 4.
4 Item 20.
Inspect the Exit Roller and Drives for wear or damage, PL 4.3. Install new components as
required.
A B
To Next Page
