Xerox® B205/B215 Multifunction Printer Service Manual
08-600 , 08-700
Status Indicator RAPs
Initial Release
08-600 Paper Jam in Duplex Area RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
B205: Jam at duplex path
B215: Jam in the Device
The machine has detected a paper jam in the Duplex Area.
Initial Actions
Remove jammed sheets from duplex area. Refer to Section 11 in the Xerox® B215/B205 User
Guide for detailed instructions on clearing paper jams.
Ensure that the paper guide and machine settings are correct for the paper that is loaded in the
tr
ay.
Procedure
Check the Exit Sensor Actuator. The actuator moves freely.
YN
Install a new Exit Sensor Actuator.
Enter Diagnostic Mode, GP
1, [DC330, [102] Out-Bin Full Sensor] to block and clear the Exit
Sensor. The sensor is OK.
YN
1. Check that there is no contamination present.
2. Check for an open or short circuit.
3. Install a new Exit Sensor, PL 4.
1 Item 24.
Check the following parts for wear or damage and replace if needed:
• Duplex Paper Guide, P
L 4.2 Item 6.
• Duplex Gate, P
L 2.1 Item 7.
• Duplex Gate Spring, PL 2.1 Item 8.
• Exit Paper Guide, PL 2.1 Item 6.
Verify the Duplex Gate is seated correctly and moves freely without binding.
08-700 Output Bin Full Fault
BSD-ON: BSD 1
Control Panel Fault Displayed
B205: Output Bin Full. Remove Paper
B215: Output Bin Full. Remove Paper
The Output Tray Full Sensor has detected that the Output Tray is full.
Initial Actions
Remove sheets from the Output Tray. (Maximum capacity is 150 sheets/ standard paper 8.5 x
11 in./ 80g/m2.)
Procedure
Enter Diagnostics Mode. Select: [Machine Test, EDC Mode, DC330 Component Control,
102-Sensor, Out Bin Full] to test the Out Bin Full Sensor. The signal changes.
YN
• Check the sensor connector is fully seated.
• Check for and remove any contamination present.
• Check for an open or short circuit.
• Install a new Output Tray Full Sensor, PL 4.
3 Item 1.
Check the Bin Full Sensor Actuator, P
L 2.2 Item 7, for binding or any debri causing the actuator
to respond intermittently or fail to actuate the Output Tray Full Sensor. Clean the Bin Full Sen-
sor Actuator and surrounding area to full operation.

Xerox B205 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	-
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	14 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIFF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution (black)	1200 x 1200 ppi
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	2 lines
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Compatibility	Xerox B205
Internal memory	256 MB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	40 sheets
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Power consumption (standby)	46 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	417 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	USB
Included cartridge capacity (black)	1500 pages
Recommended monthly print volume	2500 pages
Package weight	13000 g
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	430 mm
Width	490 mm
Height	480 mm
