Xerox B205 Service Manual

July 2019
2-19
Xerox® B205/B215 Multifunction Printer Service Manual
09-800 , 10-100
Status Indicator RAPs
Initial Release
09-800 Incompatible Toner Cartridge RAP
Control Panel Fault Displayed
B205: Invalid Print Cart.
B215: Incompatible Toner Cartridge has been Detected
The Toner Cartridge is not compatible with the printer.
Procedure
1. Press the Information button on the Control Panel, then select the menu items listed
belo
w to print the Supplies Information Report.
• WorkCentre B205: [In
fo Pages, Supplies Info].
• WorkCentre B215: [Mach
ine Status, Info Pages, Supplies Info].
2. Check the toner cartridge information. Install a new Toner Cartridge if is not a genu
ine
Xero
x® cartridge.
10-100 Fuser Temperature (Open) RAP
BSD-ON:BSD 1
Control Panel Fault Displayed
B205: Open Fuser error
B215: Fuser Error
During operation, the temperature of the F
user temperature does not increase.
WARNING
Do not handle the fuser components until they have cooled. Some fuser components
operate at hot temperatures and can produce serious personal injury if touched.
DANGER: Ne pas manipuler les éléments du four avant de les laisser refroidir. Certains
él
éments du four fonctionnent à des températures très élevées et peuvent causer de
graves blessures s'ils sont touchés.
AVVERTENZA: Non maneggiare i componenti del fusore finché non sono raffreddati.
Al
cuni di questi componenti funzionano ad alte temperature e possono provocare gravi
ferite se vengono toccati.
VORSICHT: Die Fixieranlage sollte erst gehandhabt werden, wenn diese genügend
a
bgekühlt ist. Einige Teile der Fixieranlage erzeugen übermäßige Hitze und führen bei
der Berührung zu schweren Verbrennungen.
AVISO: No manipule los componentes del fusor antes de que se enfríen. Algunos de los
co
mponentes del fusor funcionan a altas temperaturas y pueden ocasionar daños per-
sonales graves si se los toca.
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
g
raves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gr
avi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
ei
ngeschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente.
L
a máquina podría activarse y ocasionar daños personales graves.
Procedure
Switch off the machine, then verify the Fuser connection is fully seated. The Fuser connec-
tions are OK.
YN
Firmly reconnect the Fuser assembly, then switch on the machine.
Check for +3.3 VDC to the Thermistor on the Main PWB. The voltage is present.

Xerox B205 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	-
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	1
Page description languages	PCL 5, PCL 6, PostScript 3, XPS
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	14 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIFF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Optical scanning resolution (black)	1200 x 1200 ppi
Display	LCD
Product color	Black, White
Market positioning	Business
Display number of lines	2 lines
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Compatibility	Xerox B205
Internal memory	256 MB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	120 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	40 sheets
Paper tray media weight	60 - 163 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Thicker paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Power consumption (standby)	46 W
Power consumption (PowerSave)	2 W
Power consumption (average operating)	417 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	USB
Included cartridge capacity (black)	1500 pages
Recommended monthly print volume	2500 pages
Package weight	13000 g
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	430 mm
Width	490 mm
Height	480 mm
