Paper jams in areas E1 and E2
1. Open the compiler tray cover.
2. Move handle 1b to the left and remove any jammed paper.
3. Move handle 1a to the left, rotate the knob 1c, and remove any jammed paper.
4. Lift handle 2 to the right and remove any jammed paper.
5. Return handles 2, 1a, and 1b their original positions.
6. Close the compiler tray cover.
7. Follow the instructions displayed on the system’s UI to restart your print job.
Paper jams in area E3
Note
If a jam occurs after the book block leaves the compiler area, the paper is purged with
the spin glued to the book block but without a cover attached.
Xerox
®
Color 800/1000 Press
16-28
User Guide
Perfect Binder
