21. Use a damp, water-moistened (not wet), lint-free cloth to clean the paper path only
in the green lever jam clearance areas as shown in the illustration.
a) Open each area and clean the surfaces of the green-handle areas.
b) Remove any residual moisture with a dry, lint-free cloth.
22. Return lever 7a to its original position.
23. Close the left front door (print engine right side).
Replacing consumable supplies
Consumable supplies
Xerox supplies, paper, and throughput material can be ordered from Xerox by going to
www.xerox.com and clicking on either the Contact Us link for specific contact
information/telephone numbers in your area or by clicking on the Supplies and
entering/selecting your specific machine information (product family and model type).
Note
Always refer to www.xerox.com for the latest Consumable Replaceable Units (CRUs)
part numbers.
Store supply items and Xerox parts in their original packages in a convenient location.
The following items are consumables for this machine. It is recommended that you have
a supply of these items available to eliminate downtime when they need to be replaced.
Approximate Print
Yield/Carton (Full Color
Prints)
Supply Unit Shipped with
machine/Reorder Quantity
Supply Item
50K1/boxDry Ink/Toner Cartridge (Black)
55K1/boxDry Ink/Toner Cartridge (Cyan)
51K1/boxDry Ink/Toner Cartridge (Magenta)
55K1/boxDry Ink/Toner Cartridge (Yellow)
55K1/boxDry Ink/Toner Cartridge (Clear)
120k1Dry Ink/Toner Waste Bottle
400K1Fuser Web Assembly
Note
• Dry Ink/Toner yield projections are based on 7.5 percent area coverage per color (4
colors = 30 percent) at standardized conditions on A4 (8.5 x 11 in.) Xerox Digital Color
Xpressions+, 24 lb. (90 g/m
2
) and Colotech Plus 90 g/m
2
reference paper. Actual yields
vary greatly, depending on color intensity, area coverage, paper stock, and run mode
selected.
9-17
Xerox
®
Color 800/1000 Press
User Guide
Maintenance
