5-14 Phaser 3300MFP Service Manual
Print-Quality Troubleshooting
Background
Light dark background appears in whole area of the printing.
Ghost (1)
Ghost image occurs at 75.5 mm intervals of the OPC drum on the output.
Check and Cause Solution
Recycled paper has been used. Quality is not guaranteed when using
recycled paper.
The life of the Print Cartridge has
expired.
Replace the print cartridge.
Does the Transfer Roller rotate
smoothly?
Clean the bushing on the transfer roller.
The HVPS is normal? Replace the HVPS.
Check and Cause Solution
Bad contacts caused by contamination
from toner particles between high
voltage terminal in the main body and
the electrode of the Print Cartridge.
Clean the contaminated terminals.
Bad contacts caused by contamination
from toner particles between high
voltage terminal in the main body and
the one in the HVPS board.
Problem in the print cartridge. Replace
the print cartridge and re-run the job.
The life of print cartridge is expired. Replace the Control Board if not solved
by the previous suggestions.
Transfer roller life (70.000 sheets) has
expired.
If not solved by the previous suggestion,
check the transfer roller lifetime and
replace it.
Abnormal low temperature
(below 10 °C).
Wait about 1 hour after power on before
using printer.
Damaged cleaning blade in the print
cartridge.
Problem in the print cartridge, replace
the print cartridge and try to print out.
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
Digital Printer
75.5 mm
