1-4 Phaser 3300MFP Service Manual
General Information
Parts of the Printer
Front View
1 ADF (automatic document feeder) 10 Tray 1
2 Document width guides 11 Optional tray 2
3 Document input tray 12 Multi-purpose tray
4 Scanner lid 13 Output support
5 Document output tray 14 USB memory port
6 Control panel 15 Multi-purpose tray extension
7 Output tray 16 Multi-purpose tray paper width guides
8 Front cover 17 Scanner glass
9 Paper level indicator 18 Print cartridge
