Phaser 3300MFP Service Manual 8-61
Service Parts Disassembly
Xerographics
LSU
Before you remove the LSU, you must remove:
â–  Middle Cover Assembly (page 8-33)
1. Remove the four screws securing the LSU and remove it.
s3300mfp-144
