8-2 Phaser 3300MFP Service Manual
Service Parts Disassembly
Overview
This section contains the removal procedures for field-replaceable parts of the
printer listed in the Parts List. In most cases, the replacement procedure is
simply the reverse of the removal procedure. In some instances, additional
steps are necessary and are provided for replacement of the parts. For
specific assemblies and parts, refer to the “Parts List” in Section 9.
Always use the correct type and size screw. Using the wrong screw can
damage tapped holes. Do not use excessive force to remove or install
either a screw or a printer part.
The procedures are organized by the consumer replacement parts and
functions of the printer.
Maintenance Items and Consumables
■ Print Cartridge (page 8-18)
■ Tray Holder Pad (page 8-16)
■ Transfer Roller (page 8-8)
■ Pick-Up Roller (page 8-9)
■ Fuser (page 8-10)
Product Assembly
■ Covers (page 8-19)
■ Duplex (page 8-35)
■ Paper Feeder (page 8-36)
■ Scanner Assembly (page 8-47)
■ Xerographics (page 8-61)
■ Drive (page 8-63)
■ Electrical (page 8-68)
■ Options (page 8-79)
