8-4 Phaser 3300MFP Service Manual
Service Parts Disassembly
Note
Names of parts that appear in the removal and replacement procedures
may not match the names that appear in the Parts List. For example, a
part called the Registration Chute Assembly in a removal procedure may
appear on the Parts List as Assembly Registration Chute.
Note
When performing a removal procedure, ignore any prerequisite procedure
for parts already removed.
Caution
Many parts are secured by plastic tabs. DO NOT over flex or force these
parts. DO NOT over torque the screws threaded into plastic parts.
Warning
Unplug the AC power cord from the wall outlet before removing any printer
part.
Laying the Unit on its Back
Several of the procedures recommend laying the unit on its back to make the
procedure easier to perform. When laying the machine on its back, be sure to:
■ Disconnect the power and network cables from the unit.
■ Remove the Duplex Unit (page 8-35)
■ Remove the ADF Assembly (page 8-47)
■ Remove the 250-sheet Feeder option if one is installed.
