8-18 Phaser 3300MFP Service Manual
Service Parts Disassembly
Print Cartridge (PL1.0.16)
Do not expose the Print Cartridge to light for more than 5 minutes. Cover the
Print Cartridge to avoid damage.
Do not touch the green surface underneath the Print Cartridge.
1. Open the Front Cover.
2. Lift the Print Cartridge handle upward and pull the Print Cartridge out
from the machine.
