Phaser 3300MFP Service Manual 8-81
Service Parts Disassembly
6. Swing the Control Board Cover up to the closed position and slide it
forward to latch it.
Optional 250-Sheet Feeder (PL1.1.18)
Use care when removing the printer from the Optional 250-Sheet Feeder.
1. Disconnect the Tray 2 cable.
To Next Page
