8-22 Phaser 3300MFP Service Manual
Service Parts Disassembly
3. If necessary, remove the Print Cartridge.
4. Press both restraining arms to the center as indicated by the arrows until
the catches are free from the slots.
5. Swing the door downward until the door slides off the pivots on the frame.
s3300mfp-007
