Phaser 3300MFP Service Manual 8-71
Service Parts Disassembly
2. Remove the five screws securing the Control Board to the shield and
unplug the Ribbon Cable and then remove the Control Board.
s3300mfp-101
Shield
Ribbon Cable
Control Board
Machine Screw
Machine Screw
