9-6 Phaser 3300MFP Service Manual
Parts List
Parts List 1.0 Main
ID No. Name/Description
Xerox Part
Number
0 SET N/A
1 ELA HOU-FRAME 110 V —
1 ELA HOU-FRAME 220 V —
2 ELA UNIT-MAIN DRIVE (“Parts List 8.0 Main Drive
Assembly” on page 9-18)
007N01561
3 ELA HOU-MPF (“Parts List 9.0 MP Assembly” on
page 9-19)
002N02627
4 ELA UNIT-DUPLEX DRIVE —
4-1 BRACKET-P-GEAR DUP —
4-2 MOTOR STEP-DUPLEX —
4-3 GEAR-DUP RDCN 45/19 —
5 CBF HARNESS-DPX MTR —
6 CBF HARNESS-ADF CLUT1 —
7 ELA HOU-FUSER DRIVE (“Parts List 7.0 Fuser Drive
Assembly” on page 9-17)
007N01645
8 MEA-TRANSFER ROLLER 002N02628
8-1 ROLLER-TRANSFER —
8-2 GEAR-TRANSFER —
9 SHIELD-P-CONTROLLER —
10 SPEAKER —
11 PBA SUB-MODEM 140N63240
12 CBF HARNESS-ENGINE —
13 ELA HOU-MAIN RAM DIMM —
13-1 PBA MAIN-CONTROLLER (Control Board) 140N63350
13-2 PBA SUB-SDRAM —
14 ELA HOU-SCAN 4IN1 (“Parts List 10.0 Scan Assembly” on
page 9-21)
—
15 MEA-COVER —
16 ELA UNIT-DEVE INITIAL —
17 MEA UNIT-CASSETTE (“Parts List 15.0 Cassette Assembly”
on page 9-32
050N00540
23 UNIT-LSU 122N00259
24 SADDLE
25 FAN-DC 127N07485
26 MEA UNIT-DUPLEX 022N02381
27 SHIELD-P-SMPS —
28 CBF HARNESS-AC INLET —
29 CBF HARNESS-LSU S/W —
