Phaser 3300MFP Service Manual 9-23

Parts List

Parts List 11.0 Platen Assembly

ID No. Name/Description

Part Number

0 ELA HOU-PLATEN 090N00166

1 MEA-SCAN UPPER —

1-1 MEA UNIT-SCAN DUMMY 500N00108

1-1-1 COVER-M_SCAN DUMMY —

1-1-2 MCT-GLASS ADF —

1-1-3 TAPE-DOUBLE FACE —

1-1-4 TAPE ETC-DOUBLE TAPE SMALL —

1-1-5 LABEL (P)-SHADING —

1-1-6 TAPE-DOUBLE FACE —

1-2 COVER-M_SCAN UPPER 101N01410

1-3 GLASS-SCAN 057N00156

1-4 TAPE-DOUBLE FACE —

1-5 IPR-HOLDER GLASS —

2 ELA HOU-SCAN LOWER 109N00692

2-1 COVER-M_SCAN LOWER —

2-2 ELA HOU-SCAN MOTOR 127N07530

2-2-1 BRACKET-SCAN MOTOR R2 —

2-2-2 GEAR-TIMING —

2-2-3 PMO-HOLDER BELT —

2-2-4 RING-E —

2-2-5 GEAR-IDLE —

2-2-6 GEAR-REDUCTION73/37 —

2-2-7 MOTOR STEP-SCAN —

2-3 ELA HOU-CCDM_2905 101N01409

2-4 ICT-SHAFT CCD —

2-5 CBF SIGNAL-CCD FFC 143N00017

2-6 PMO-PULLEY —

2-7 BELT-TIMING GEAR 109N00542

2-9 RING-E —

2-10 SPRING ETC-BELT —

2-11 SPRING-CS —

2-12 PMO-LEVER SENSOR 011N00473

2-13 PHOTO-INTERRUPTER 130N01274

2-14 CBF HARNESS-PLA_COVER —

2-15 CBF HARNESS-ADF LOWER —
