9-34 Phaser 3300MFP Service Manual
Parts List
Parts List 16.0 Fuser Assembly
ID No. Name/Description Part Number
0 FUSER UNIT 220V REP 4 (includes items 1-42) 126N00266
0 FUSER UNIT 110V REP 4 (includes items 1-42) 126N00265
1 FUSER COVER —
2 IDLE 23 GEAR —
3 FUSER HARNESS CONNECTOR —
4 THERMOSTAT 130N01490
5 THERMISTOR 130N01489
6 IDLE ROLLER HOLDER —
7 IDLE UPPER ROLLER —
8 REC HARNESS —
9 STRIPPER FINGER —
10 FINGER STRIPPER SPRING —
11 RUBBER EXIT_F/UP —
12 PEX ROLLER F/UP —
13 SPRING-TS —
14 ANTISTATIC BRUSH —
15 FUSER FRAME —
16 RIGHT JAM LINK LEVER —
17 LEFT JAM LINK LEVER —
18 E-CLIP —
19 JAM LINK HOLDER —
20 HALOGEN LAMP 110V 122N00260
20 HALOGEN LAMP 220V 122N00261
20-1 HEAT ROLLER 022N02371
20-2 HEAT ROLLER LEFT BUSH —
20-3 HEAT ROLLER RIGHT BUSH —
20-4 HEAT ROLLER GEAR —
21 INPUT GUIDE —
22 REAR GUIDE —
23 EXIT SENSOR ACTUATOR —
24 ACTUATOR SPRING —
25 PMO BUSHING TX —
26 EXIT F/UP SHAFT —
27 IDLE F/UP —
28 REAR GUIDE SPRING COVER —
