9-36 Phaser 3300MFP Service Manual

Parts List

Parts List 17.0 Duplex Unit (Optional)

ID No. Name/Description

Part Number

0 MEA UNIT-DUPLEX (includes items 1-16) 098N02194

1 FRAME-M_DUP 050N00521

2 GUIDE-M_DUMMY —

3 BUSH-M-FEED, DUP —

4 ELA UNIT-ROLLER_DUP2 —

5 PULLEY-18-DUP —

6 GEAR-EXIT F/DOWN —

7 ELA UNIT-ROLLER_DUP —

8 PULLEY-M-18-DUMMY_DUP —

9 SCREW-TAPTITE —

10 TERMINAL-P-GND DUP —

11 GUIDE-M_UPPER DUP —

12 SPRING-TS —

13 PCT-SILP WASHER —

14 ROLLER-M-IDLE_ DUP —

15 SHAFT-IDLE ROLL, DUP —

16 BELT-TIMING —
