2-8 Phaser 3300MFP Service Manual
Theory of Operation
Fuser Assembly
■ Fusing Type: Halogen Lamp (R2)
■ Heat Roller: 28.3 with 0.1 Crown
■ Pressure Roller: Electrically conductive
■ Thermistor - Temperature Detecting Sensor
■ Thermostat - Overheat Protection Device
s3300mfp-149
