4-4 Phaser 3300MFP Service Manual
General Troubleshooting
DIAL MODE
This function can choose dial method.
*Default: Dial (Dial/Pulse)
MODEM SPEED
You can set the maximum modem speed.
Communication is done with modem speed automatically set at lower speed
when communicating with a slower speed modem since communication is
done on the standard of the side where modem speed is low for transmission/
reception. It is best set 33.6 Kbps as default setting.
ERROR RATE
When the error rate is about exceed the set value, the Baud rate automatically
adjusts to 2400 bps.
This ensures that the error rate remains below the set value.
You can select the rate between 5% and 10%.
CLEAR ALL MEMORY
The function resets the system to factory default settings.
This function is used to reset the system to the initial value when the product
is functioning abnormally. All the values are returned to the default values, and
all the information, which was set by the user, will be erased.
Method
1. Select the [MEMORY CLEAR] at the TECH MODE.
2. Push the ENTER button.
3. Select you country. (There are four country groups. Refer to the table
below.)
4. Push the ENTER button then it will clear all memory.
Always perform a memory clear after replacing the Control Board.
Otherwise, the system may not operate properly.
