Xerox WorkCentre 3345 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-57
Bypass Empty
The Bypass Tray is empty.
Applicable Error
• 07-500: Paper Empty at Bypass Tray
Initial Actions
• Load originals in the Bypass Tray.
• If problem persists use the following procedure.
Troubleshooting Reference Table
Troubleshooting Procedure Table
Applicable Parts Wiring and Plug/Jack Map Reference
• Bypass Paper Empty Sensor, (PL 3.2.10,
Parts List 3.2 Bypass Tray)
• Main PWB: Phaser 3330 (PL 1.0.7, Parts
List 1.0 Phaser 3330 Main), WorkCentre
3335 and 3345 (PL 6.1.7, Parts List 6.1
WorkCentre 3335/3345 Main).
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
Step Actions and Questions Yes No
1. Enter dC330 Component Control, code
07-510 to check the Bypass Paper Empty
Sensor and Empty MP Actuator.
The display changes when the sensor is
actuated?
Go to step 4. Go to step 2.
2. Check that the sensor and actuator are
correctly installed and undamaged.
The sensor and actuator are good?
Go to step 3. Go to step 3.
3. Install a new Tray 2 Paper Empty Sensor (PL
12.4.5, Parts List 12.4 Optional Tray Feeder
Pick Up Unit Assy).
If necessary, install a new Empty MP
Actuator ,(PL 3.2.8, Parts List 3.2 Bypass
Tray).
Does the error persist?
Go to step 3. Complete.

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
