Xerox WorkCentre 3345 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-5
Parts List 1.0 Phaser 3330 Main
Note: All Main PWB spare parts are configured with a SOLD service plan. Any device with a
METERED billing plan will require a Plan Conversion Code to be entered to re-enable metered
support. Failure to do this may result in Invalid Toner Messages. Always follow all steps outlined in
the Main PWB replacement procedure.
Item Name Part Number
1
Front Cover Assembly (REF: PL 1.3)
002N03326
2 Tray 1 Cassette Assembly (REF: PL 5.1) 050N00694
3 Right Cover Assembly 002N03325
4 Main Frame (REF: PL 3.1) -
5 Left Cover 002N03324
6 SMPS (110V) 105N02330
- SMPS (220V) 105N02331
7 Main PWB (See Note) 140N63796
8 Duplex Assembly (REF: PL 4.1) 022N02856
9 Fuser (110V) (REF: PL 3.3) 126N00410
- Fuser (220V) (REF PL 3.3) 26N00411
10 Rear Frame (REF: PL 3.4) 001N00534
11 Rear Door 095N00415
12 LSU (Laser Unit) 130N01853
13 Top Cover 002N03323
14 Wireless Board 140N63805
15 SD Card 091N80340

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
