Parts Lists
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
5-12
Parts List 1.3 Front Cover Assembly
Item Name Part Number
1Front Cover -
2 Front Door Sensor 130N01601
3TS Spring -
4Front Locker -
5Zcrum Harness -
6Cover Link -
7 Front Cover Inner -
8 Front Button -
9 Crum PWB 140N63808
10 Front Door -
11 MP Left Adjust -
12 MP Right Adjust -
13 Rack Pinion Gear (FX) -
14 MP Lower Tray -
15 Upper Tray -
16 MP Extension Tray -
17 Front Cover Assembly
Note: Move the Tag Matrix Label to the new Front Cover
Assembly.
002N03326
