Xerox WorkCentre 3345 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-33
PL 6.1 WorkCentre 3335/3345 Main
Note: All Main PWB spare parts are configured with a SOLD service plan. Any device with a
METERED billing plan will require a Plan Conversion Code to be entered to re-enable metered
support. Failure to do this may result in Invalid Toner Messages. Always follow all steps outlined in
the Main PWB replacement procedure.
Item Name Part Number
1
Front Cover Assembly (REF: PL 1.3)
002N03326
2 Tray 1 (REF:PL 5.1) 050N00694
3 Right Cover (REF:PL.1.2) 002N03333
4 Main Frame (REF: PL 3.1) -
5 Left Cover 002N03332
6 SMPS (110V) 105N02330
SMPS (220V) 105N02331
7 Main PWB (3335) (See Note) 140N63797
Main PWB (3345) (See Note) 140N63798
8 Duplex Assembly (REF: PL 4.1) 022N02856
9 Fuser (110V) (REF: PL 3.3) 126N00410
Fuser (220V) (REF: PL 3.3) 126N00411
10 Rear Frame (REF: PL 3.4) 001N00534
11 Rear Door 095N00415
12 LSU (Laser Unit) 130N01853
13 Lower Middle Cover 002N03336
14 Upper Middle Cover -
15 Control Panel Assy Refer to Parts List 10.1 WorkCentre
3335/3345 Control Panel (PL
10.1.22)
16
WorkCentre 3335 ADF (REF: PL 7.1)
-
16A
WorkCentre 3345 DADF (REF: PL 8.1)
-
17 Wireless Board 140N63805
18 SD Card 091N80340
19 Surge Protector (South Africa Only) 005N01172
20 Flat Cable (Modem Cable) 117N02065

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
