Xerox WorkCentre 3345 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-39
Parts List 7.1A WorkCentre 3335 ADF (2/2)
Item Name Part Number
1 ADF 022N02859
2Screw -
3 Rubber Pad 108R01472
4Drive Gear -
5 White Bar 025N00104
6Roller -
7Paper Stopper -
8Idle Gear -
9 Gear Separate Roller -
10 Roller Pickup 130N01673
11 Pick up Housing 130N01854
12 Housing Pickup Assembly -
13 Sensor Harness -
14 Antistatic Brush -
15 Motor Bracket -
16 ADF Motor 127N07781
17 Front Edge Guide -
18 Rear Edge Guide -
19 Stacker -
20 Rear ADF Cover -
21 Front ADF Cover -
22 Cover Platen -
23 Slide Stopper -
24 Position Paper Actuator -

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
