Xerox WorkCentre 3345

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-61
Parts List 12.4 Optional Tray Feeder Pick Up Unit Assy
Item Name Part Number
1 Terminal MEA Unit -
2 Roller MEA Unit 108R01471
3 Pick Brush -
4 Paper Empty Actuator -
5 Paper Empty Sensor -
6 REGI Roller -
7 Idle Roller-M -
8 Idle One Way Holder-M -
9 Harness-GND -
10 Feed Sensor Harness -
11 Motor SW Harness -
12 A/S Com-Frame Feed -
13 CSP-SCF Actuator Feed -
