Xerox WorkCentre 3345 Service Manual

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-20
09-100 Toner Low Toner is almost empty. Toner
may be low or Toner may be
unevenly distributed.
Ensure a replacement
cartridge is in stock. Use
little more change if
“Toner Low” is marked in
LCD window.
Toner Low
09-200 Toner Cartridge
Empty
Empty Toner Cartridge
detected.
Replace the Toner
Cartridge.
Replace
Toner
Cartridge or
SMart Kit
Drum
Cartridge
09-230 Toner Cartridge
Writing Error
Toner Cartridge information
did not get written to CRUM.
POPO the machine. If fault
persists, replace the Toner
Carriage.
09-240 Toner Cartridge
communication
error
No communication with the
CRUM in the Toner Cartridge.
POPO the machine. If fault
persists, replace the Toner
Carriage.
09-250 Toner Cartridge read
error
Toner Cartridge information
could not be read.
POPO the machine. If fault
persists, replace the Toner
Carriage.
09-300 Drum Warning Drum Cartridge is nearing
the end of life based on the
number of prints made.
Ensure a replacement
cartridge is in stock. Use
little more change if
“REPLACE DRUM” is
marked in LCD window.
09-330 Drum Cartridge
communication
error
No communications with the
CRUM in the Drum Cartridge.
POPO the machine. If fault
persists, replace the Drum
Carriage.
09-340 Drum Cartridge
read error
No communications with the
Drum Cartridge.
POPO the machine. If fault
persists, replace the Drum
Carriage.
Error Error Message Cause Initial Action Go To

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
