Troubleshooting
8. If no prompt appears when paper is loaded, set the paper type and size.
a. At the printer control panel, press the Home button.
b. Touch Device > Paper Trays.
c. To open the Bypass Tray menu, touch the Bypass Tray icon. It is displayed in the top position,
before the numbered trays.
d. To select a paper or envelope size, touch the current size setting, then from the list, select a size.
e. To select a paper type, touch the current paper type, then from the list, select a paper type.
f. To save the setting, touch OK.
g. To return to the Home screen, press the Home button.
Clearing Paper Jams from the Tray 1 Area
To resolve the error displayed on the control panel, you must clear all paper from the paper path.
1. Remove any paper from the Bypass Tray.
2. Grasp both sides of the Bypass Tray, then pull it straight out of the printer.
Xerox
®
WorkCentre
®
6515 Color Multifunction Printer 203
User Guide

Xerox WorkCentre 6515 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 2400 dpi
Scan Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Fax Resolution	Up to 400 x 400 dpi
Monthly Duty Cycle	Up to 50, 000 pages
Automatic Duplexing	Yes
Functions	Print, Copy, Scan, Fax
Memory	2 GB
Fax Speed	33.6 Kbps
Paper Output	150 sheets
Fax Transmission Speed	3 seconds per page
Standard Paper Capacity	300 sheets
Connectivity	USB, Ethernet
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria, Xerox Print Service Plug-in for Android
Maximum Paper Size	8.5 x 14 inches
Dimensions	420 x 506 x 500 mm
Print Speed	Up to 30 ppm
Paper Input	Bypass Tray: 50 sheets; Tray 1: 250 sheets
