Xilinx Zynq UltraScale+ ZCU216 - Page 12

IMPORTANT! The following gure is for visual reference only and might not reect the current revision of the
board.
IMPORTANT! There could be mulple revisions of this board. The specic details concerning the dierences
between revisions are not captured in this document. This document is not intended to be a reference design
guide and the informaon herein should not be used as such. Always refer to the schemac, layout, and XDC
les of the specic ZCU216 version of interest for such details.
Chapter 2: Board Setup and Configuration
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 12
