Xilinx Zynq UltraScale+ ZCU216 User Manual

Table 32: Medium Frequency Balun Part Number (cont'd)
Parameter Value
Data Sheet See the Anaren website.
Figure 37: Medium Frequency Balun Specifications
Figure 38: Medium Frequency Balun Drawing
0.68+0.072.04+0.10
1.29+0.10
Orientation Marker
Denotes Pin Location
TOP VIEW (Near Side) SIDE VIEW
6x 0.98
BOTTOM VIEW (Far Side)
2x 0.15
1
4x 0.37
2 3
6 5 4
6x 0.22
6x 0.30
4x 0.65
Pin
1
2
3
4
5
6
Designation
Unbalanced
GND/DC Feed
+RF GND
Balanced Port
Balanced Port
GND
NC
Orientation Marker
Denotes Pin Location
Mechanical Outline
-Dimensions are in Millimeters
X23307-093019
High Frequency Baluns
High Frequency Balun (4-5 GHz)
Table 33:
High Frequency Balun (4-5 GHz) Part Number
Parameter Value
Part Number BD3150N50100AHF
Manufacturer Anaren
Order P/N 1173-1069-2-ND
Appendix C: XM650/XM655 Balun Add-on Cards for RFSoC EVM
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 87
Send Feedback
