Table 9: I2C0 Port Expander TCA6416A U15 Connections (cont'd)
TCA6416A U15
Schematic Net Name
Connected To
Pin
Name
Pin No. Pin No. Pin Name
Reference
Designator
Device
P02 6 MIO26_PMU_INPUT_LS A34 PS_MIO26 U1 XCZU49DR
P04 8 DAC_AVTT_VOUT_SEL 1 G Q36 NDS331N
P05 9 IIC_MUX_RESET_B 3 RESET_B U20 TCA9548A
P06 10 GEN3_EXP_RESET_B 2 B U34 SN74LVC1G08
P07 11 MAX6643_FULL_SPEED 6 FULLSPD U50 MAX6643
P10 13 FMCP_HSPC_PRSNT_M2C_B
H2 PRSNT_M2C_L J28(H) ASP_184329_01
Z1 PRSNT_M2C_L J28(N) ASP_184329_01
P13 16 VCCINT_VRHOT_B 14 VRHOT_ICRIT
#
U104 IR35215
P15 18 8A34001_EXP_RST_B 1 A U415 SN74LVC1G08
P16 19 IRPS5401_ALERT_B
11 SM_ALERT# U104 IR35215
17 ALERT_B U53, U55 IRPS5401
17 SALERT#
U112, U123,
U127
IR38164
P17 20 INA226_PMBUS_ALERT 3 ALERT
U57, U58,
U59,U60, U61,
U62, U63,
U64, U65,
U67, U71,
U75, U77,
U124
INA226
The addresses of each target device on the I2C0 U17 PCA9544A switch are idened in the
following table.
Table 10: I2C0 Multiplexer PCA9544A U17 Target Device Addresses
PCA9544A U17 (Addr 0x75) Port I2C0 Bus Device Target Device Address
0 INA226_PMBus (Power Monitors) 0X40-0x43, 0x45-0x4E
1 Not Connected N/A
2 IRPS5401_PMBus (Voltage Regulators) 0X40, 0x43, 0x44, 0x45, 0x4B, 0x4C
3 SYSMON U1 bank 65 0X32
I2C1 (MIO 16-17)
[Figure 2, callout 18]
I2C bus I2C1 connects RFSoC U1 PS Bank 500, PL bank 89, and system controller U38 to two
I2C switches (TCA9548A U20 and U22). These I2C1 connecons enable I2C communicaons
with various I2C capable target devices. TCA9548A U20 is pin-strapped to respond to I2C
address 0x74. TCA9548A U22 is pin-strapped to respond to I2C address 0x75.
Chapter 3: Board Component Descriptions
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 33
Send Feedback
