Block Diagram
XM655: 16T16R Breakout Add-on Card
Figure 23: XM655 Block Diagram
XM650: 16T16R N79 Band Loopback Demo Add-on Card
Figure 24: XM650 Block Diagram
Appendix C: XM650/XM655 Balun Add-on Cards for RFSoC EVM
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 71
