Xilinx Zynq UltraScale+ ZCU216 User Manual

Chapter 1
Introduction
Overview
The ZCU216 is an evaluaon board featuring the ZU49DR Zynq
®
UltraScale+™ RFSoC Gen3
device. This board enables evaluaon of applicaons requiring sub-6 GHz Bands for Radio,
mmWave, and full L-band and S-Band in Phased Array Radar. The ZCU216 board is equipped
with all the common board-level features needed for design development like DDR4 memory,
networking interfaces, an FMC+ expansion port as well as access to the RFMC 2.0 interface.
Document Audience and Scope
The purpose of this guide is to familiarize system architects, soware developers, and hardware
designers with the ZCU216 evaluaon board. The ZCU216 evaluaon board features the Zynq
UltraScale+ RFSoC ZU49DR. The ZCU216 board enables the demonstraon, evaluaon, and
development of numerous applicaons.
Additional Resources
See Appendix E: Addional Resources and Legal Noces for references to documents, les, and
resources relevant to the ZCU216 evaluaon board.
Block Diagram
A block diagram of the ZCU216 evaluaon board is shown in the following gure.
Chapter 1: Introduction
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 5
Send Feedback

Xilinx Zynq UltraScale+ ZCU216 Specifications

General

Brand	Xilinx
Model	Zynq UltraScale+ ZCU216
Category	Motherboard
Language	English
