Xilinx Zynq UltraScale+ ZCU216 User Manual

Board Component Descriptions
The following table idenes the components and references the respecve schemac
(038-05003-01) page numbers.
Table 2: ZCU216 Board Component Locations
Callout
Ref.
Des.
Feature
[B]=Bottom
Notes
Schematic
Page
1 U1 Zynq
®
UltraScale+™ RFSoC Fansink XCZU49DR-2FFVF1760
COFAN 30-4988-10
2 J48 DDR4 SODIMM SOCKET w/64-bit DDR4
SODIMM
LOTES ADDR0067-P001A w/MICRON
MTA4ATF51264HZ-2G6E1
Note: J48 is bottomside.
43
3 U96-U99 DDR4 C0 4x8-bit Clamshell Component
Memory (4 GB)
Micron MT40A1G8WE-075E
Note: U96 and U97 are bottomside.
68-71
4 U100-
U103
DDR4 C1 4x8-bit Clamshell Component
Memory (4 GB)
Micron MT40A1G8WE-075E
Note: U102 and U103 are bottomside.
72-75
5 U11, U12 Dual Quad SPI Flash Memory (4 Gb
total)
Micron MT25QU02CBB8E12-0SIT 23
6 U6, J18 USB 3 ULPI Transceiver [B], USB Micro-
AB Connector
SMSC USB3320-EZK, WURTH
692122030100
22
7 J23 SD Card Interface Connector Hirose DMIAA-SF-PET(21) 26
8 U29, J24 Quad USB_UART, USB micro-B
Connector
FTDI FT4232Hx-REEL, Hirose ZX62D-
AB-5P8
27
9 J25 JTAG 2 mm 2x7 Flat-Cable Connector Molex 87832-1420 27
10 U43 Fixed Freq. Clock Gen. [B] Silicon Labs SI5341B-D07833-GM 39
11 U47 (C0),
U130 (C1)
User Clock, 300 MHz, 3.3V LVDS [B] Silicon Labs SI570BAB001614DG 45
12 U48 User MGT Clock, 156.250 MHz, 3.3V LVDS Silicon Labs SI570BAB000544DG 45
13 External SFP Jitter Attenuated Clock CLK104 module function (J101) 67
14 J101 CLK104 Module Connector Samtec LPAF-20-03.0-L-06-2-K-TR 67
15 J29 Quad zSFP/zSFP+ Connector TE Connectivity/AMP 2198325-5 36
16 U33, P1 10/100/1000 MHz Ethernet PHY, RJ45
w/Mag
TI DP83867IRPAP, Wurth 7499111221A 28
17 U17, U15 I2C0 Bus Switch, Expander [B] TI PCA9544ARGYR, TI TCA6416APWR 24
18 U20, U22 I2C1 Bus Switches [B] 2 ea. TI TCA9548APWR 25
19 U38 System Controller (SC) TI MSP430F5342 30
20 J24 MSP430 SC Emulation Cable Connector TYCO 5103308-2 30
21 SW6, SW7 System Controller 5-pole DIP Switch and
Reset PB Switch
5-pole C&K SDA05H1SBD,
E-Switch TL3301EP100QG
30
22 J46, J47 PMOD0/1 RA Receptacles SULLINS PPPC062LJBN-RC 42
Chapter 2: Board Setup and Configuration
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 14
Send Feedback
