Xilinx Zynq UltraScale+ ZCU216 User Manual

Table 2: ZCU216 Board Component Locations (cont'd)
Callout
Ref.
Des.
Feature
[B]=Bottom
Notes
Schematic
Page
45 U115,
U116
ADC/DAC AVCC Regulators [B] MPS MPM3683-7 56
46 U114 ADC AVCCAUX 2A Regulator [B] MPS MPM3833C 57
47 U125 DAC AVCCAUX Regulator [B] MPS MPM3833C 58
48 U118 DAC AVTT Regulator [B] MPS MPM3833C 58
Default Jumper and Switch Settings
The following gure shows the ZCU216 board jumper header and switch locaons. Each
numbered component shown in the gure is keyed to the applicable table in this secon. Both
tables reference the respecve schemac page numbers.
Chapter 2: Board Setup and Configuration
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 16
Send Feedback
