○ 2 ADC inputs - compression mount SMAs through high freq baluns – Anaren
BD4859N50100AHF
○ 2 DAC outputs compression mount SMAs through low frequency baluns – Minicircuits
TCM2-33WX+
○ 2 DAC outputs compression mount SMAs through mid frequency baluns – Anaren
BD1631J50100AHF
○ 2 DAC outputs compression mount SMAs through high frequency baluns – Anaren
BD3150N50100AHF
○ 2 DAC outputs - compression mount SMAs through high freq baluns – Anaren
BD4859N50100AHF
○ 20 DACIO digital I/O pins on a header strip
○ 20 ADCIO digital I/O pins on a header strip
○ 12V, 5V0, 3V3, VCCADJ DAC, VCCADJ_ADC, DAV_AVTT, and GND, I2C signals access on
a header strip.
The XM650 balun add-on card demonstraons DAC to ADC loopback with a 16T16R
conguraon of N79 baluns and lters. There is no external connecvity to the ADC or DAC
signals. Digital IO and I2C are supported on headers.
Following are the features of XM650 module:
○ 16 DAC outputs looped back to 16 ADC inputs
○ 32 N79 baluns and lters on the card
- B46 or N77 band baluns can be supported with BOM change or re-work by customers.
○ 20 DACIO digital I/O pins on a header strip
○ 20 ADCIO digital I/O pins on a header strip
12V, 5V0, 3V3, VCCADJ DAC, VCCADJ_ADC, DAV_AVTT, and GND access on a header strip.
Board Specifications
Board Dimensions/Form Factor
When the module is mated with ZCU216 RFMC 2.0 connectors (Samtec LPAF-50-03.0-L-08-2-
K-TR), the mated height between the boards will be 4.0 mm. No component is placed on the
boom side of the module.
• XM655 Dimensions:
Length: 9.85" (250.19 mm)
Appendix C: XM650/XM655 Balun Add-on Cards for RFSoC EVM
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 79
