Xilinx Zynq UltraScale+ ZCU216 User Manual

The ZCU216 evaluaon board uses power management ICs (PMIC) and regulators from Inneon
Integrated Circuits and MPS to supply the core and auxiliary voltages listed in the following table.
Reference schemac 038-05003-01.
Table 25: ZCU216 Power System Devices
Ref. Des.,
PMBUS ADDR
Controller or
Regulator
Rail Name Voltage (V)
Max. Current
(A)
INA226
Power
Monitor
INA226
PMBUS ADDR
Sense Resistor
(Ω)
Schem.
Page
PMIC1 U104
(0X40)
IR35215_PWM1/
2
V
CCINT
0.85 60 U65 0x40 R440: 0.0005
47
IR35215_PWM1_
L2
V
CCINT_AMS
0.85 28 U61 0x49 R1098: 0.0005
PMIC2 U53
(0X44)
IRPS5401_A V
CC1V2
1.2 6 U58 0x43 R408: 0.005
50
IRPS5401_B UTIL_1V13 1.13 500 mA NA NA NA
IRPS5401_C VADJ_FMC
1.8 6 U62 0x45 R382: 0.005
IRPS5401_D Tied to channel
C
IRPS5401_LDO MGT1V8 1.8 500 mA U64 0x48 R787: 0.005
PMIC3 U55
(0X45)
IRPS5401_A NC NA NA NA NA NA
52
IRPS5401_B UTIL_2V5 2.5 500 mA NA NA NA
IRPS5401_C MGT1V2
1.2 7 U63 0x47 R400: 0.005
IRPS5401_D Tied to 3C
IRPS5401_LDO MGTRAVCC 0.85 500 mA NA NA NA
U127 (0X4B) IR38164 V
CCINT_IO_BRAM_PS
0.85 18 U57 0x41 R1099: 0.0005 53
U112 (0x43) IR38164 MGTAVCC 0.9 4 U67 0x46 R455: 0.002 54
U123 (0x4C) IR38164 VCC1V8 1.8 8 U60 0x42 R879: 0.002 55
U115 MPM3683-7 ADC_AVCC 0.925 4 U75 0x4C R499: 0.005 56
U116 MPM3683-7 DAC_AVCC 0.925 6 U77 0x4E R504: 0.005 56
U114 MPM3833C ADC_AVCCAUX 1.8 2 U71 0x4D R475: 0.005 57
U125 MPM3833C DAC_AVCCAUX 1.8 1.5 U124 0x4B R889: 0.005 58
U118 MPM3833C DAC_AVCCAUX 2.5/3.0 1.5 U59 0x4A R869: 0.005 58
U111 IR3889 UTIL_3V3 3.3 15 NA NA NA 60
U126 IR3889 UTIL_5V0 5 10 NA NA NA 61
U79 IR3897 PL_DDR4_C0_VT
T
0.6 +/- 3.0 NA NA NA 61
U108 IR3897 PL_DDR4_C1_VT
T
0.6 +/- 3.0 NA NA NA 61
U80 IR3897 PS_DDR4_VTT 0.6 +/- 3.0 NA NA NA 62
The FMCP HSPC (J28) V
ADJ
pins and RFSoC U1 banks 66 and 67 V
CCO
pins are wired to the
programmable rail VADJ_FMC. The VADJ_FMC rail is programmed to 1.80V by default.
Documentaon describing PMBUS programming for the Inneon power controllers as well as
PMIC and voltage regulator data sheets are available on the Inneon Integrated Circuits website.
Non-PMBus ADC and DAC voltage regulator data sheets can be viewed on the MPS website.
