Table 20: Power and Status LEDs (cont'd)
Ref. Des.
Schematic Net
Name
LED
Color
Description
DS38 UTIL_2V5_PG Green UTIL_2V5 2.5VDC Power ON
DS39 UTIL_3V3_PG Green UTIL_3V3 3.3VDC Power ON
DS40 UTIL_5V0_PG Green UTIL_5V0 5VDC Power ON
DS41 PS_DDR4_VTERM_0V6
0_PG
Green PS_DDR4_VTERM 0.6VDC Power ON
DS42 PL_C0_DDR4_VTERM_
0V60_PG
Green PL_C0_DDR4_VTERM 0.6VDC Power ON
DS43 PL_C1_DDR4_VTERM_
0V60_PG
Green PL_C1_DDR4_VTERM 0.6VDC Power ON
DS44 DAC_AVCCAUX_ON Green DAC_AVCCAUX 1.8VDC Power ON
DS46 RGB_[R,G,B]_LED_0 R,G,B USER GPIO RGB LED_0
DS47 RGB_[R,G,B]_LED_1 R,G,B USER GPIO RGB LED_1
DS48 RGB_[R,G,B]_LED_2 R,G,B USER GPIO RGB LED_2
DS49 RGB_[R,G,B]_LED_3 R,G,B USER GPIO RGB LED_3
DS50 RGB_[R,G,B]_LED_4 R,G,B USER GPIO RGB LED_4
DS51 RGB_[R,G,B]_LED_5 R,G,B USER GPIO RGB LED_5
DS52 RGB_[R,G,B]_LED_6 R,G,B USER GPIO RGB LED_6
DS53 RGB_[R,G,B]_LED_7 R,G,B USER GPIO RGB LED_7
The following gure shows the GPIO and power status LED areas of the board.
Chapter 3: Board Component Descriptions
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 53
