Xilinx Zynq UltraScale+ ZCU216 User Manual

J55 DAC
48 GND GND GND GND GND GND GND GND
49 GND GND GND GND GND DAC228_T0_
CH0_N
DAC228_T0_
CH0_P
GND
50 GND GND GND GND GND GND GND GND
J49 ADC
A B C D E F G H
1 GND GND GND GND GND GND GND GND
2 GND ADC227_T3_
CH3_N
ADC227_T3_
CH3_P
GND GND GND GND GND
3 GND GND GND GND GND GND GND GND
4 GND GND GND GND GND GND GND GND
5 GND GND GND GND GND ADC227_T3_
CH2_N
ADC227_T3_
CH2_P
GND
6 GND GND GND GND GND GND GND GND
7 GND ADC227_T3_
CH1_N
ADC227_T3_
CH1_P
GND GND GND GND GND
8 GND GND GND GND GND GND GND GND
9 GND GND GND GND GND GND GND GND
10 GND GND GND GND GND ADC227_T3_
CH0_N
ADC227_T3_
CH0_P
GND
11 GND GND GND GND GND GND GND GND
12 GND ADC226_T2_
CH3_N
ADC226_T2_
CH3_P
GND GND GND GND GND
13 GND GND GND GND GND GND GND GND
14 GND GND GND GND GND GND GND GND
15 GND GND GND GND GND ADC226_T2_
CH2_N
ADC226_T2_
CH2_P
GND
16 GND GND GND GND GND GND GND GND
17 GND ADC226_T2_
CH1_N
ADC226_T2_
CH1_P
GND GND GND GND GND
18 GND GND GND GND GND GND GND GND
19 GND GND GND GND GND GND GND GND
20 GND GND GND GND GND ADC226_T2_
CH0_N
ADC226_T2_
CH0_P
GND
21 GND GND GND GND GND GND GND GND
22 GND ADC225_T1_
CH3_N
ADC225_T1_
CH3_P
GND GND GND GND GND
23 GND GND GND GND GND GND GND GND
24 GND GND GND GND GND GND GND GND
25 GND GND GND GND GND ADC225_T1_
CH2_N
ADC225_T1_
CH2_P
GND
26 GND GND GND GND GND GND GND GND
27 GND ADC225_T1_
CH1_N
ADC225_T1_
CH1_P
GND GND GND GND GND
Appendix C: XM650/XM655 Balun Add-on Cards for RFSoC EVM
UG1390 (v1.1) July 10, 2020 www.xilinx.com
ZCU216 Board User Guide 75
Send Feedback
