XT2640OperatingManual 13July2016 Page156of187

Sub‐Field
Sub‐field
Format
Value Description
POHC
PartialOddHarmonicCurrent(onlyvalidwhenusedwithAMPS
dataforachannel)
PWHC
PartialWeightedHarmonicCurrent(onlyvalidwhenusedwith
AMPSdataforachannel)
EndingHarmonic(onlyusedif
MeasurementTypeisH1…500or
%2…500)
NR1 1to500
Dataincludesharmonicsuptoandincludingthisnumber (ifthis
sub‐fieldisnotspecifiedthendataonlyincludesthesingleharmonic
specifiedintheMeasurementTypesub‐field)
Alistofallowedcombinationsisprovidedbelow.Inthislistthefollowingcodesareusedtoreducethelengthofthelist–
CHn AnyofCH1,CH2,CH3orCH4
An AnyofA1,A2orA3
pX AnyofpA,pB,pCorpD
Hn AnyofH1…500
n Anyof1…500
Pn AnyofP1…500
%n Anyof%2…500or%S2…500
Notallcombinationsshownmaybeallowedinallcircumstances;channelsmightnotbeinstalledortheconfigurationmaynot
providevalidresultsforaspecificcombination.Notallvalidcombinationsmaybeshownbelowandwhereadefaultsub‐fieldvalue
maybeusedthecombinationisonlyshownwithoutdefiningthatspecificsub‐field.
FREQ:CHn
FREQ:CHn:STBYMIN
FREQ:CHn:STBYMAX
FREQ:An
INTEGTIME:CHn:INTEG
INTEGTIME:CHn:CHARGE
INTEGTIME:CHn:DISCHARGE
INTEGTIME:CHn:BOUGHT
INTEGTIME:CHn:SOLD
INTEGTIME:An:INTEG
INTEGTIME:An:CHARGE
INTEGTIME:An:DISCHARGE
INTEGTIME:An:BOUGHT
INTEGTIME:An:SOLD
STBYTIME:CHn
STBYTIME:An
VOLTS:CHn:DC
VOLTS:CHn:AC
VOLTS:CHn:ACDC
VOLTS:CHn
VOLTS:CHn:RECTIFIED
VOLTS:CHn:FF
VOLTS:CHn:CF
VOLTS:CHn:PK
VOLTS:CHn:VALLEY
VOLTS:CHn:PK‐VLY
VOLTS:CHn:HIPK
VOLTS:CHn:LOPK
VOLTS:CHn:INRUSH
VOLTS:CHn:INRUSHPK
VOLTS:CHn:INRUSHVLY
VOLTS:CHn:INTEG
VOLTS:CHn:INTAVG
VOLTS:CHn:CHARGE
VOLTS:CHn:DISCHARGE
VOLTS:CHn:BOUGHT
VOLTS:CHn:SOLD
VOLTS:CHn:Hn
VOLTS:CHn:Hn:n
VOLTS:CHn:Pn
VOLTS:CHn:THDf
VOLTS:CHn:THDsig
VOLTS:CHn:%n
VOLTS:CHn:%n:n
VOLTS:CHn:STBY
VOLTS:CHn:STBYMIN
VOLTS:CHn:STBYMAX
VOLTS:CHn:STBYCFMIN
VOLTS:CHn:STBYCFMAX
VOLTS:CHn:STBYTHDMAX
VOLTS:An:pX:DC
VOLTS:An:pX:AC
VOLTS:An:pX:ACDC
VOLTS:An:pX
VOLTS:An:pX:RECTIFIED
VOLTS:An:pX:FF
VOLTS:An:pX:CF
VOLTS:An:pX:PK
VOLTS:An:pX:HIPK
VOLTS:An:pX:LOPK
VOLTS:An:pX:INRUSH
VOLTS:An:pX:INRUSHPK
VOLTS:An:pX:INTEG
VOLTS:An:pX:INTAVG
VOLTS:An:pX:CHARGE
VOLTS:An:pX:DISCHARGE
VOLTS:An:pX:BOUGHT
VOLTS:An:pX:SOLD
VOLTS:An:pX:Hn
VOLTS:An:pX:Hn:n
VOLTS:An:pX:Pn
VOLTS:An:pX:THDf
VOLTS:An:pX:THDsig
VOLTS:An:pX:%n
VOLTS:An:pX:%n:n
VOLTS:An:pAC:AC
VOLTS:An:pAC:ACDC
VOLTS:An:pAC
VOLTS:An:pAC:RECTIFIED
VOLTS:An:pAC:FF
VOLTS:An:pAC:CF
VOLTS:An:pAC:PK
VOLTS:An:pAC:HIPK
VOLTS:An:pAC:LOPK
VOLTS:An:pAC:INRUSH
VOLTS:An:pAC:INRUSHPK
VOLTS:An:pAC:INTEG
VOLTS:An:pAC:INTAVG
VOLTS:An:pAC:BOUGHT
VOLTS:An:pAC:SOLD
VOLTS:An:pAC:Hn
VOLTS:An:pAC:Hn:n
VOLTS:An:pAC:Pn
VOLTS:An:pAC:THDf
VOLTS:An:pAC:THDsig
VOLTS:An:pAC:%n
VOLTS:An:pAC:%n:n
VOLTS:An:pBC:AC
VOLTS:An:pBC:ACDC
VOLTS:An:pBC
VOLTS:An:pBC:RECTIFIED
VOLTS:An:pBC:FF
VOLTS:An:pBC:CF
VOLTS:An:pBC:PK
VOLTS:An:pBC:HIPK
VOLTS:An:pBC:LOPK
VOLTS:An:pBC:INRUSH
VOLTS:An:pBC:INRUSHPK
VOLTS:An:pBC:INTEG
VOLTS:An:pBC:INTAVG
VOLTS:An:pBC:BOUGHT
VOLTS:An:pBC:SOLD
VOLTS:An:pBC:Hn
VOLTS:An:pBC:Hn:n
VOLTS:An:pBC:Pn
VOLTS:An:pBC:THDf
VOLTS:An:pBC:THDsig
VOLTS:An:pBC:%n
VOLTS:An:pBC:%n:n
VOLTS:An:pAB:AC
VOLTS:An:pAB:ACDC
VOLTS:An:pAB
VOLTS:An:pAB:RECTIFIED
VOLTS:An:pAB:FF
VOLTS:An:pAB:CF
VOLTS:An:pAB:PK
VOLTS:An:pAB:INRUSH
VOLTS:An:pAB:INRUSHPK
VOLTS:An:pAB:Hn
VOLTS:An:pAB:Hn:n
VOLTS:An:pAB:Pn
VOLTS:An:pAB:THDf
VOLTS:An:pAB:THDsig
VOLTS:An:pAB:%n
VOLTS:An:pAB:%n:n
VOLTS:An:SEQZERO
VOLTS:An:SEQPOS
VOLTS:An:SEQNEG
VOLTS:An:WYE
VOLTS:An:DELTA
VOLTS:An
VOLTS:An:RECTIFIED
VOLTS:An:PK
VOLTS:An:INRUSH
VOLTS:An:INRUSHPK
VOLTS:An:INTEG
VOLTS:An:INTAVG
VOLTS:An:CHARGE
VOLTS:An:DISCHARGE
VOLTS:An:BOUGHT
VOLTS:An:SOLD
VOLTS:An:H1
VPH‐PH:CHn:DC
VPH‐PH:CHn:AC
VPH‐PH:CHn:ACDC
VPH‐PH:CHn
VPH‐PH:CHn:RECTIFIED
VPH‐PH:CHn:FF
VPH‐PH:CHn:CF
VPH‐PH:CHn:PK
VPH‐PH:CHn:Hn
VPH‐PH:CHn:Hn:n
VPH‐PH:CHn:THDf
VPH‐PH:CHn:THDsig
VPH‐PH:CHn:%n
VPH‐PH:CHn:%n:n
AMPS:CHn:DC
AMPS:CHn:AC
AMPS:CHn:ACDC
AMPS:CHn
AMPS:CHn:RECTIFIED
AMPS:CHn:FF
AMPS:CHn:CF
AMPS:CHn:PK
AMPS:CHn:VALLEY
AMPS:CHn:PK‐VLY
AMPS:CHn:HIPK
AMPS:CHn:LOPK
AMPS:CHn:INRUSH
AMPS:CHn:INRUSHPK
AMPS:CHn:INRUSHVLY
AMPS:CHn:INTEG
AMPS:CHn:INTAVG
AMPS:CHn:CHARGE
AMPS:CHn:DISCHARGE
AMPS:CHn:BOUGHT
AMPS:CHn:SOLD
AMPS:CHn:Hn
AMPS:CHn:Hn:n
AMPS:CHn:Pn
AMPS:CHn:THDf
AMPS:CHn:THDsig
AMPS:CHn:%n
AMPS:CHn:%n:n
AMPS:CHn:STBY
AMPS:CHn:STBYMIN
AMPS:CHn:STBYMAX
AMPS:CHn:STBYCFMAX
AMPS:CHn:THC
AMPS:CHn:POHC
AMPS:CHn:PWHC
AMPS:An:pX:DC
AMPS:An:pX:AC
AMPS:An:pX:ACDC
AMPS:An:pX
AMPS:An:pX:RECTIFIED
AMPS:An:pX:FF
AMPS:An:pX:CF
AMPS:An:pX:PK
AMPS:An:pX:HIPK
AMPS:An:pX:LOPK
AMPS:An:pX:INRUSH
AMPS:An:pX:INRUSHPK
AMPS:An:pX:INTEG
AMPS:An:pX:INTAVG
AMPS:An:pX:CHARGE
AMPS:An:pX:DISCHARGE
AMPS:An:pX:BOUGHT
AMPS:An:pX:SOLD
AMPS:An:pX:Hn
AMPS:An:pX:Hn:n
AMPS:An:pX:Pn
AMPS:An:pX:THDf
AMPS:An:pX:THDsig
