ADPRO
®
FastTrace™ 2 Series Hardware Installation Manual
21790_05 33
Choose Advanced > Event log > Event logging and select the option Disable.
Choose Advanced > Chipset Configuration > HPET and select the option Disable.
Choose Power > After Power Failure and select the option Power-On.
Choose Exit > Exit & Save Changes and select the option Yes.
All other parameters can be left to the default settings.
6.2.3 Intel DH61BE Motherboard
Choose Main > System Time to set the system time.
Choose Main > System Date to set the system date.
Choose Configuration > SATA drives > Smart and select the option Disable.
Choose Configuration > SATA drives > Chipset SATA mode and select the option AHCI.
Choose Configuration > Event log > Event logging and select the option Disable.
If necessary (with newer BIOS versions): Choose Security > Chassis Intrusion and select the option
Disable.
Choose Power > After Power Failure and select the option Power-On.
Choose Boot > Hard drive order and place the DOM CSS HSV40-256M at the top of the list, using the
arrows keys on the keyboard to select the DOM, and the + key to move the selected DOM upwards. Press
Enter.
Choose Exit > Exit & Save Changes and select the option Yes.
All other parameters can be left at the default settings.
Note
With the Intel DH61BE motherboard, you need to reset the BIOS settings every time you
replace or add a hard disk.
6.2.4 MiTAC PH10LU Motherboard
Choose Main > System Time to set the system time.
Choose Main > System Date to set the system date.
Choose Chipset > PCH-IO Configuration > Front Panel Audio and select the option Legacy Front Panel.
Choose Boot > CSM parameters > Launch PXE OPROM policy and select the option Legacy only.
Choose Save & Exit > Exit and Reset and press Enter.
All other parameters can be left at the default settings.
6.3 Replacing the Motherboard
Do not replace the motherboard in the field. If the motherboard needs replacing, send back the server to
your supplier.
6.4 Replacing the Motherboard Battery
It may be necessary to replace the motherboard battery after some time of specific battery faults. For further
instructions, see the technical documentation of the specific motherboard.
