FastTrace™ 2 Series Hardware Installation Manual
21790_05 105
25.2.2 FastTrace 2E Units
Each product version has an 8-digit product number, indicating the installed options.
The product number layout is made up as: 58 VV HH I D
58
The FastTrace 2E product number
VV
The video channel type:
 10 = 4 analogue
 20 = 8 analogue
 30 = 12 analogue
 40 = 16 analogue
 50 = 20 analogue
 01 = 4 IP
 02 = 8 IP
 03 = 12 IP
 04 = 16 IP
 05 = 20 IP
 11 = 4 analogue and 4 IP
 12 = 4 analogue and 8 IP
 13 = 4 analogue and 12 IP
 14 = 4 analogue and 16 IP
 21 = 8 analogue and 4 IP
 22 = 8 analogue and 8 IP
 23 = 8 analogue and 12 IP
 31 = 12 analogue and 4 IP
 21 = 12 analogue and 8 IP
 41 = 16 analogue and 4 IP
HH
The hard disk size:
Single disk
RAID 1 Ready
2x RAID 1 Ready
11 = 1x 500 GB
21 = 2x 500 GB
41 = 4x 500 GB
12 = 1x 1 TB
22 = 2x 1 TB
42 = 4x 1 TB
13 = 1x 2 TB
23 = 2x 2 TB
42 = 4x 2 TB
14 = not used
24 = not used
42 = not used
15 = 1x 4 TB
25 = 2x 4 TB
42 = 4x 4 TB
16 = 1x “X” TB*
26 = 2x “X” TB*
42 = 4x “X” TB*
…
…
…
19 = 1x “X” TB*
22 = 2x “X” TB*
42 = 4x “X” TB*
00 = Transmission (FastTrace 2 TX) only (1 TB)
* X is to be defined in the future.
I
I/O option:
 0 = no I/O
 1 = 1 MIO (8 inputs, 4 outputs)
 2 = 1 MIO + 1 EIO (20 inputs, 8 outputs)
 3 = 2 MIO (16 inputs, 8 outputs)
 4 = 2 MIO + 1 EIO (28 inputs, 12 outputs)
 5 = 2 MIO + 2 EIO (40 inputs, 16 outputs)
D
Special options:
 0 = no special options
 1 = DTC (Down The Coax) card inserted
 2 = Bundle (+ 2 IntrusionTrace licenses)
 3 = Bundle (+ 2 IntrusionTrace licenses) and DTC (Down The Coax) card
