20 Current Consumption
Estimated current consumption depends on the installed components and on the system load:
Motherboard
16 W (Intel)
Processor
25 W (AMD)
Intel DG31, DG41: 65 W max.
Intel DH55: 73 W max.
Intel DH61: 77 W max.
4 channel A/V card
3.5 W
8 channel A/V card
7 W
Western digital RE hard disk
11 W
Western digital RE2 hard disk
12 W
Main I/O card
1 W
Extension I/O card
1 W
HIPI card (for IP cameras)
3 W
DTC card (“Down the Coax”)
0.5 W
Example (with maximum values):
Motherboard
16 W
Processor
77 W (DH61BE with Core i7 microprocessor)
Two 8-channels A/V cards
14 W
4 Western Digital RE2 hard disks
48 W
Main I/O card
1 W
Extension I/O card
1 W
TOTAL
on secondary circuit
on primary circuit (total current consumption
divided by 0.8 – this is the efficiency of the
power supply)
157 W
196 W (0.80 A / 230 VAC)
Note
Measurement on a fully equipped (*) FastTrace 2 server (with DH61BE motherboard and G850
microprocessor) produced the following results: 0.41 A at 230 VAC  95 W (idle state).
(*) Fully equipped = FastTrace 2 server with 2 Main I/O cards, 1 Extension I/O card, 1 HIPI
card, two 8-channel A/V cards, and 4 hard disks (2 TB per disk).
