FastTrace™ 2 Series Hardware Installation Manual
21790_05 9
1 Technical Specifications
The FastTrace 2 unit is the current video security system within the ADPRO
®
FastTrace™ series. It has been
developed as a high performance video security unit that can either be managed by CMS software
(e.g. M3000) or by the ADPRO XOa client.
Operating system
PC platform – Linux OS
Network protocols
TCP, UDP, FTP, Telnet, HTTP, SMTP, RTSP, RTP
Bandwidth
Remotely adjustable: compression, fps, and quality.
You can specify a bandwidth limit.
Bandwidth consumption
6 fps CIF/SIF: 70 kbps
12 fps 4CIF/SIF: 400 kbps in optimal quality
Software updates
Local and remote
Maximum number of
cameras
FastTrace 2/2X: 16 (total of analogue and IP cameras)
FastTrace 2E: 32 (total of analogue and IP cameras)
Analogue cameras (*)
FastTrace 2/2X: 4, 8, 12, or 16 analogue A/V inputs
FastTrace 2E: 4, 8, 12, 16, or 20 analogue A/V inputs
Video:
 PAL or NTSC
 BNC connectors (1.0 Vp-p; 75 ohm)
 Max. cable length: 350 m (RG59); 610 m (RG11)
Audio:
 1 input per analogue camera
 Screw connectors
 Input level: 2.0 Vp-p; 1000 ohm
Analogue cameras
Video resolution PAL
QCIF (176 x 144)
CIF (352 x 288)
2CIF (704 x 288)
DCIF (528 x 384) (not available with DS42xx A/V cards)
4CIF (704 x 576)
Analogue cameras
Video resolution NTSC
QSIF (176 x 120)
SIF (352 x 240)
2SIF (704 x 240)
DSIF (528 x 320) (not available with DS42xx A/V cards)
4SIF (704 x 480)
Analogue cameras
images/second PAL
CIF, 2CIF, DCIF: 25 fps / camera
4CIF: 15 fps / camera (25 fps with DS42xx A/V cards)
Analogue cameras
images/second NTSC
QSIF, SIF, 2SIF, DSIF: 30 fps / camera
4SIF: 15 fps / camera (25 fps with DS42xx A/V cards)
IP cameras (**)
Up to 20 IP cameras on a dedicated IP network.
Optional network interface required:
 1 HIPI card per 8 IP cameras
 FastTrace 2E: 1 Ethernet card for up to 32 IP cameras (with XOa software,
Intel DH61BE or MiTAC PH10LU motherboard and 4 GB RAM or more)
With MiTAC PH10LU motherboard: no separate network card required.
Only H.264 video streaming can be used.
Audio input is supported.
Video resolution and
images/second
Depends solely on the IP camera type.
Maximal HD/MP resolution.
