Xtralis ADPRO FastTrace 2 series User Manual

Hardware Installation Manual ADPRO
®
FastTrace™ 2 Series
36 21790_05
Slot
Type
Accepts
2
PCI Express
Main I/O
Extension I/O
HIPI (ETH1) for 8 IP cameras
3
PCI
Main I/O
Extension I/O
A/V with 4 or 8 channels (lowest camera numbers: CAM 1 > 4/8)
4
PCI
Main I/O
Extension I/O
A/V with 4 or 8 channels (highest camera numbers: CAM 5/9 > 8/16)
5
/
Extension I/O
6
/
Main I/O
7.3.1.3 The Xtralis Configurations
Analogue Cameras (4 – 8 – 12 – 16 Channels)
Slot
Type
Extension Card
1
PCI Express
Extension I/O 2
2
PCI Express
Main I/O 2
3
PCI
A/V 4 channels 1 or A/V 8 channels 2
4
PCI
A/V 8 channels 1
5
/
Extension I/O 1
6
/
Main I/O 1
IP Cameras (8 or 16 Channels)
Slot
Type
Extension Card
1
PCI Express
HIPI (ETH1)
2
PCI Express
HIPI (ETH2)
3
PCI
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Hybrid (12 Channels)
Slot
Type
Extension Card
1
PCI Express
HIPI (ETH1)
2
PCI Express
Extension I/O 2
3
PCI
A/V 4 channels 1
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
