FastTrace™ 2 Series Hardware Installation Manual
21790_05 47
7.3.5.2 The Xtralis Configurations
The table below shows the possible configurations with a MiTAC PH10LU motherboard:
Slot
Type
1
PCI
Express
2
PCI
Express
3
PCI
Express
4
PCI
Express
5
–
6
–
Analogue 4 ch
A/V 4 ch
–
EIO 2
MIO 2
EIO 1
MIO 1
Analogue 8 ch
A/V 8 ch
–
Analogue 12 ch
A/V 4 ch
A/V 8 ch
Analogue 16 ch
A/V 16 ch
–
Analogue 20 ch
A/V 16 ch
A/V 4 ch
Digital 1–32 ch
–
–
Hybrid 32 ch (4 analogue)
A/V 4 ch
–
Hybrid 32 ch (8 analogue)
A/V 8 ch
–
Hybrid 32 ch (12 analogue)
A/V 4 ch
A/V 8 ch
Hybrid 32 ch (16 analogue)
A/V 16 ch
–
Analogue x ch = unit with analogue cameras only, x = the number of channels
Digital x ch = unit with IP cameras only, x = the number of channels
Hybrid x ch (y analogue) = unit with analogue and IP cameras, x = the total number of channels, y = the
number of analogue channels
A/V x ch = analogue video card, x = the number of channels
